DRONE ACCESSORIES
Weight and Payload
Gimbal Weight
(including gimbal, battery grip, and quick-release plate)
890 g (2 lbs)
1.4 kg (3.0 lbs)
1.6 kg (3.5 lbs)
Tested Payload
2 kg (4.4 lbs)
3 kg (6.6 lbs)
4.5 kg (10 lbs)
Recommended Camera and Lens Combination
Sony: A7S3/A7M4/A7C + FE 24-70 mm F2.8 GM II
Sony: A6400 + E 16-50 mm F3.5-5.6
Canon: EOS R5 + RF 24-70 mm F2.8
Canon: EOS R7 + RF 15-30 mm F4.5-6.3
Nikon: Z7 II + Z 24-70 mm F2.8
Nikon: Z50 + Z 24-50 mm F4.0-6.3
Panasonic: S5 + L 20-60mm F3.5-5.6
Fujifilm: FX-T30 II + XC 15-45 mm F3.5-5.6
Sony: A6400 + E 16-50 mm F3.5-5.6
Canon: EOS R5 + RF 24-70 mm F2.8
Canon: EOS R7 + RF 15-30 mm F4.5-6.3
Nikon: Z7 II + Z 24-70 mm F2.8
Nikon: Z50 + Z 24-50 mm F4.0-6.3
Panasonic: S5 + L 20-60mm F3.5-5.6
Fujifilm: FX-T30 II + XC 15-45 mm F3.5-5.6
Sony: A7S3/A7M4/A7C/A1 + FE 24-70 mm F2.8
Canon: R5/R6 + RF 24-70 mm F2.8
Nikon: Z6 II/Z7 II + Z 24-70 mm F2.8
Panasonic: GH6 + M4/3 12-60 mm F2.8-4.0
Fujifilm: X-T4 + X 16-55 mm F2.8
Canon: R5/R6 + RF 24-70 mm F2.8
Nikon: Z6 II/Z7 II + Z 24-70 mm F2.8
Panasonic: GH6 + M4/3 12-60 mm F2.8-4.0
Fujifilm: X-T4 + X 16-55 mm F2.8
Red: Komodo + RF 24-70 mm F2.8
Blackmagic Design: BMPCC 6K Pro + EF 24-70 mm F2.8
Sony: FX6/FX3 + FE 24-70 mm F2.8
Canon: C70/R5C/R3 + RF 24-70 mm F2.8
Nikon: Z9 + Z 24-70 mm F2.8
Panasonic: S1H + L 24-70 mm F2.8
Blackmagic Design: BMPCC 6K Pro + EF 24-70 mm F2.8
Sony: FX6/FX3 + FE 24-70 mm F2.8
Canon: C70/R5C/R3 + RF 24-70 mm F2.8
Nikon: Z9 + Z 24-70 mm F2.8
Panasonic: S1H + L 24-70 mm F2.8
Use Scenarios
Standalone Gimbal
Single-handed, briefcase, 3rd-gen native vertical shooting
Single-handed, dual-handed, briefcase, 2nd-gen native vertical shooting
Single-handed, dual-handed, briefcase, 2nd-gen native vertical shooting
Expansion
N/A
Briefcase control handle, ring handle
Vehicle mount, Steadicam, slider, cable cam, jib
Gimbal Design
Axis Locks
2nd-gen automated axis locks
2nd-gen automated axis locks
2nd-gen automated axis locks
Axis Arm Material
Aluminum alloy, Teflon™ interlayers
Aluminum alloy, Teflon™ interlayers
Carbon fiber, Teflon™ interlayers
Appearance
Conventional design
Ronin next-gen red and black design
Ronin next-gen red and black design
Balancing Experience
Quick-Release Plate
Dual-layered (with adjustable placement guide),
Positioning slots in the upper quick-release plate
Positioning slots in the upper quick-release plate
Dual-layered (with adjustable placement guide)
Dual-layered (with adjustable placement guide), extended
Fine-Tuning Knob
Yes
Yes
Yes
Key Features
Stabilization Algorithm
4th-Gen RS Stabilization Algorithm
4th-Gen RS Stabilization Algorithm
4th-Gen RS Stabilization Algorithm
Shutter Connection
Bluetooth, shutter release cable
Bluetooth, shutter release cable
Bluetooth, shutter release cable
Parameter Setting Screen
1.4″ LCD full-color touchscreen
1.8″ OLED full-color touchscreen
1.8″ OLED full-color touchscreen
Shortcut
Gimbal mode switch, joystick mode switch
Gimbal mode switch, joystick mode switch
Gimbal mode switch, joystick mode switch
Accessory Ecosystem
Focusing System
N/A
N/A
2nd-gen LiDAR focusing system (multi-point)
Video Transmission System
N/A
DJI Ronin Image Transmitter
DJI Transmission, DJI Ronin Image Transmitter
Intelligent Tracking and Composition
DJI RS Intelligent Tracking Module
DJI RS Intelligent Tracking Module
DJI RS Intelligent Tracking Module
Expansion Port
NATO port × 1
USB-C control port × 1
USB-C control port × 1
RSA port × 1
NATO port × 2
Charging adapter port × 1
USB-C control port × 3
NATO port × 2
Charging adapter port × 1
USB-C control port × 3
RSA port × 2
NATO port × 2
Charging adapter port × 1
USB-C control port × 3
NATO port × 2
Charging adapter port × 1
USB-C control port × 3
Charging and Runtime
Battery Design
Not detachable
Detachable
Detachable
Runtime
13 hours
Max 29.5 hours*
* Require the DJI RS BG70 High-Capacity Battery Grip, which is sold separately. Data was measured in a controlled environment. Actual experience may vary. For details, please refer to the product page on the official DJI website.
Max 29 hours*
* Require the DJI RS BG70 High-Capacity Battery Grip, which is sold separately. Data was measured in a controlled environment. Actual experience may vary. For details, please refer to the product page on the official DJI website.
Charging Time
1 hour 50 minutes
2.5 hours
1.5 hours
